Skylar
$0.00
Lumio Skylar 48 DC ceiling fan w/remote – white
- Efficient DC motor keeps running costs low
- 12 speeds for customised comfort all year round
- Remote includes reverse and timer functions
- Strong airflow up to 12,750 m³/hr
- ABS blades and body for long lasting use
- Compact 48 size for bedrooms and living rooms
- 6 year warranty (4 in home, 2 return to base)
Specifications
Mechanical
| IP Rating | IP20 |
|---|---|
| Fitting Colour | Matt White |
| Body Material | ABS |
Electrical
| Working Temp Range | -10 to 40 °C |
|---|---|
| Input Frequency | 50Hz Hz |
| Input voltage | 230Vac |
| In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6% | |
Air Movement
| Motor Wattage | 40 W |
|---|---|
| Motor Type | DC |
| No. Speeds | 12 |
| Control | Remote control |
| Ceiling Rake | 13 ° |
| Ceiling Drop | 300 mm |
| Blade Pitch | 13 ° |
| Blade Material | ABS |
| Fan Size | 1220mm (48inch) |
| Fan Speed 1 | 2.52 W, 90 rpm, 310 m³/h |
| Fan Speed 2 | 6.67 W, 150 rpm, 680 m³/h |
| Fan Speed 3 | 10.6 W, 180 rpm, 860 m³/h |
| Fan Speed 4 | 13.6 W, 195 rpm, 930 m³/h |
| Fan Speed 5 | 16.5 W, 210 rpm, 990 m³/h |
| Fan Speed 6 | 19.5 W, 225 rpm, 1050 m³/h |
| Fan Speed 7 | 22.5 W, 235 rpm, 1090 m³/h |
| Fan Speed 8 | 25.4 W, 240 rpm, 1150 m³/h |
| Fan Speed 9 | 28.5 W, 255 rpm, 1195 m³/h |
| Fan Speed 10 | 32.5 W, 265 rpm, 1210 m³/h |
| Fan Speed 11 | 35.5 W, 270 rpm, 1230 m³/h |
| Fan Speed 12 | 40 W, 285 rpm, 1275 m³/h |
Compliance
| Standards |
|
|---|
Warranty
| Domestic Use Warranty | 4 Onsite, 2 RTB (Total 6 years) |
|---|
Dimensions
| Product Height | 320 mm |
|---|---|
| Product Width | 1220 mm |
| Product Weight | 4000 g |
SKYLAR/48
Ordering Information
| Order code | Item code | Description | Availability |
|---|---|---|---|
| 15247 | Skylar 48 | Lumio Skylar 48 (1220mm) DC ceiling fan - white |
Documents & Downloads
Instruction Manual
Datasheet
*Auto generated datasheet (beta)
