Aeris
Lumio Aeris 48 DC ceiling fan w/wall controller – white
- Energy-saving DC motor for lower power bills
- 3 speeds controlled from the wall – no lost remotes
- Strong airflow up to 12,000 m³/hr
- Compact 48 size suits bedrooms and small areas
- Powder coated steel blades built to last
- Works on flat or raked ceilings up to 13°
- 6 year warranty (4 in home, 2 return to base)
Specifications
Mechanical
| IP Rating | IP20 |
|---|---|
| Fitting Colour | Matt White |
| Body Material | ABS |
Electrical
| Working Temp Range | -10 to 40 °C |
|---|---|
| Input Frequency | 50Hz Hz |
| Input voltage | 230Vac |
| In Australia the Input voltage is defined as 230Vac -6%/+10%. This effectively means that the voltage range of these products are 216Vac - 253Vac or 240V +6% | |
Air Movement
| Motor Wattage | 35 W |
|---|---|
| Motor Type | DC |
| No. Speeds | 3 |
| Control | Wall control |
| Ceiling Rake | 13 ° |
| Ceiling Drop | 300 mm |
| Blade Pitch | 11 ° |
| Blade Material | Powdercoated passivated steel |
| Fan Size | 1220mm (48inch) |
Compliance
| Standards |
|
|---|
Warranty
| Domestic Use Warranty | 4 Onsite, 2 RTB (Total 6 years) |
|---|
Dimensions
| Product Height | 310 mm |
|---|---|
| Product Width | 1220 mm |
| Product Weight | 4300 g |
AERIS/48
Ordering Information
| Order code | Item code | Description | Availability |
|---|---|---|---|
| 15243 | Aeris 48 | Lumio Aeris 48 (1220mm) Industrial DC ceiling fan w/wall controller - white |
Documents & Downloads
Datasheet
*Auto generated datasheet (beta)
